On-line infrared temperature measurement system continuously NKTEM2000]

NKTEM2000 infrared continuous temperature measuring system

For the integration of integrated infrared thermometer, sensors, optical system integration together with the electronic circuit.

Product features:

- measuring range 0 ~ 500 ° C

- 4-20 mA linear output, optical resolution to 15:1

- optical resolution to 15:1.

- 300 ms response time.

- power supply is 24 VDC / 20 mA.

NKTEM2000 performance indicators:

NKTEM2000红外连续测温系统

为一体化集成式红外测温仪，传感器、光学系统与电子线路共同集成。
产品特性：

- 测量范围0 ～500°C
- 4-20 mA 线形输出, 光学分辨率为15:1
- 光学分辨率为15:1。
- 300毫秒响应时间。
- 电源为24VDC/20 mA。

NKTEM2000性能指标：

TYPE 型号	NKTEM2000
Measuring range 测量范围	0-500℃
Distance coefficient 距离系数	15:1
emissivity 发射率	0.95
Accuracy of measurement 测量精度	测量值的±1%或±1.5℃ Taking the maximum
repetitive 重复性	测量值的±0.5%或±1℃, Taking the maximum
The response time 响应时间	300ms(95%)
output 输出	4-20 mA The linear output 线形输出
The environment temperature 环境温度	0-60℃
power supply 工作电源	24VDC/20mA
material 材料	Aluminum alloy 铝合金
size 尺寸	55mm×60mm(diameter 直径)
cable length 电缆长度	1.5M(default set标配)
protective 保护	IP65(NEMA-4)
